- LDMOS Transistors（横方向拡散型MOSトランジスタ）
- Multi Market 12/28/32V
MG3503S
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| A2 | 2.5-3.5GHz | General | 40 | 28 | 40% | 9.5 | Full band CW | Released | 資料 |
MX0514
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| LBB | HF-1GHz | General | 70×2 | 28 | 60% | 18 | 1GHz,P1dB,CW | Released | 資料 |
M2K1025RVP
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| B4E | HF-1GHz | General | 85×2 | 28 | 60% | 18 | 1GHz,P1dB,CW | Released | 資料 |
MX0520
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| LBB | HF-1GHz | General | 100×2 | 28 | 60% | 17 | 1GHz,P1dB,CW | Released | 資料 |
MX0525
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| LBB | HF-1GHz | General | 125×2 | 28 | 60% | 17 | 1GHz,P1dB,CW | Released | 資料 |
MX1060VP
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| LBB | HF-0.6GHz | General | 125×2 | 28 | 60% | 18 | 0.6GHz,P1dB,CW | Released | 資料 |
MX1530G
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| LBB | 0.2-0.7GHz | General | 150×2 | 28 | 70% | 18 | 0.5GHz,P1dB,CW | Released | 資料 |
MX0540X
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| LBB | HF-0.2GHz | General | 200×2 | 28 | 70% | 17 | 0.2GHz,P1dB,Pulse | Released | 資料 |
MQ0523R
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| D4E | HF-1GHz | General | 115×2 | 28 | 65% | 15 | 0.5GHz, P3dB, CW | Released | 資料 |
MQ0530
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| D4E | HF-0.5GHz | General | 150*2 | 28 | 65% | 18 | 0.5GHz,P1dB,CW | Released | 資料 |
MQ0534R
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| D4E | HF-0.5GHz | General | 170×2 | 28 | 65% | 17 | 0.5GHz,P1dB,CW | Released | 資料 |
MQ1535CR
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| D4E | 0.2-0.7GHz | General | 175×2 | 28 | 70% | 15 | 0.7GHz,P1dB,CW | Released | 資料 |
MQ1548GR
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| D4E | 0.2-0.6GHz | General | 240×2 | 28 | 65% | 15 | 0.5GHz, P1dB, CW | Released | 資料 |
MQ0550X
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| D4E | HF-0.3GHz | General | 250×2 | 28 | 70% | 16 | 0.3GHz, P1dB, CW | Released | 資料 |
MQ0580X
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| D4E | HF-0.1GHz | General | 300×2 | 28 | 75% | 20 | 50MHz, P3dB, CW | Released | 資料 |
MJ1509
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| LBB | HF-1.5GHz | General | 45×2 | 28 | 60% | 18 | 1GHz,P1dB,CW | Released | 資料 |
MG2503S
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| A2 | 2.0-3.0GHz | General | 40 | 28 | 40% | 11 | Full band CW | Released | 資料 |
MG2004S
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| A2 | 1.0-2.0GHz | General | 40 | 28 | 50% | 12 | Full band CW | Released | 資料 |
MG1707S
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| A2 | 1.1-1.7GHz | General | 70 | 28 | 50% | 12 | Full band CW | Released | 資料 |
MC1225S
| Package | Frequency Band | Application | Pout(W) | Voltage(V) | Efficiency(%)@ rated power | Power Gain(dB) | Condition | Status | |
|---|---|---|---|---|---|---|---|---|---|
| C2 | 0.96-1.2GHz | Avionics | 250 | 32 | 55% | 14 | Full band CW | Released | 資料 |
